General view

CDB432E

IPRS Băneasa

Also known as
54LS32, 74LS32
Year
Unknown
Category
Components
Type
Integrated circuits
Documentation score
1/5
Last edited
23 OCT 2026

Specifications

Type
TTL digital integrated circuit
Function
quadruple 2-input OR gates
Package
TO-116
Logic family
TTL (standard), TTL-LS (see Variants)
Operating temperature range
0…+70 °C, −55…+125 °C (see Variants)
Supply voltage (VS)
4.75…5.25 V, 4.50…5.50 V (see Variants)

Sources: [1][2]

Variants (4)

Note
CDB432ETTL (standard)0…+70 °C4.75…5.25 V
CDB432EMTTL (standard)−55…+125 °C4.50…5.50 V
54LS32TTL-LS−55…+125 °C4.50…5.50 Vpreliminary data
74LS32TTL-LS0…+70 °C4.75…5.25 V

Click a column heading to sort. „+” adds a variant to the comparison (CDB432E).

Description

The CDB432E is a TTL digital integrated circuit of the CDB series of IPRS Băneasa: quadruple 2-input OR gates [1].

The I.P.R.S. Băneasa Full Line Condensed Catalog (1990) lists the CDB432E and CDB432EM together with the 54LS32 (marked as preliminary data) and the 74LS32, as quadruple 2-input OR gates in a TO-116 package, with the logic function Y = A+B [1]. By the catalog’s table of families, the CDB432E and 74LS32 work at 0…+70 °C from a 4.75…5.25 V supply, and the CDB432EM and 54LS32 at −55…+125 °C from 4.50…5.50 V [2].

Gallery

IPRS Băneasa CDB432E: Pinout (1990 catalogue)No image available
Pinout (1990 catalogue)
IPRS Băneasa CDB432E: TO-116 case outline (dimensions in mm)No image available
TO-116 case outline (dimensions in mm)

Documents

No documents available yet.

References

  1. [1]I.P.R.S. Băneasa – „Full Line Condensed Catalog”, 1990, section 1 „Digital integrated circuits”, „T.T.L. families”, p. 1-08
  2. [2]I.P.R.S. Băneasa – „Full Line Condensed Catalog”, 1990, section 1 „Digital integrated circuits”, „General informations”, „Basic characteristics”, p. 1-XX
