CDB837E
IPRS Băneasa
- Manufacturer
- IPRS Băneasa
- Country
- Romania
- Year
- Unknown
- Category
- Components
- Type
- Integrated circuits
- Documentation score
- 1/5
- Last edited
- 23 OCT 2026
Specifications
- Type
- TTL digital integrated circuit
- Function
- hex unified bus receivers
- Package
- MP-117
- Logic family
- TTL (standard) (see Variants)
- Operating temperature range
- 0…+70 °C, −55…+125 °C (see Variants)
- Max. propagation delay (tPLH max)
- 30–50 ns (see Variants)
- Supply voltage (VS)
- 4.75…5.25 V, 4.50…5.50 V (see Variants)
Variants (3)
| Note | Compare | |||||
|---|---|---|---|---|---|---|
| CDB837E | TTL (standard) | 0…+70 °C | 30 | 4.75…5.25 V | ||
| CDB837EM | TTL (standard) | −55…+125 °C | 30 | 4.50…5.50 V | preliminary data | |
| CDB837EA | — | — | 50 | — |
Click a column heading to sort. „+” adds a variant to the comparison (CDB837E).
Description
The CDB837E is a TTL digital integrated circuit of the CDB series of IPRS Băneasa: hex unified bus receivers [1].
The I.P.R.S. Băneasa Full Line Condensed Catalog (1990) lists the CDB837E, CDB837EM (marked as preliminary data) and CDB837EA as hex unified bus receivers in an MP-117 package [1]. By the catalog’s table of families, the CDB837E works at 0…+70 °C from a 4.75…5.25 V supply, and the CDB837EM at −55…+125 °C from 4.50…5.50 V [2].
It gives the maximum propagation delay tPLH as 30 ns for the CDB837E and CDB837EM and 50 ns for the CDB837EA [1].
Gallery
No image available
No image availableDocuments
No documents available yet.
References
- [1]I.P.R.S. Băneasa – „Full Line Condensed Catalog”, 1990, section 1 „Digital integrated circuits”, „T.T.L. families”, p. 1-27
- [2]I.P.R.S. Băneasa – „Full Line Condensed Catalog”, 1990, section 1 „Digital integrated circuits”, „General informations”, „Basic characteristics”, p. 1-XX
